Bettersize – Dynamic Image Particle Analyzer with Dry Dispersion – BeVision D2
The BeVision D2 particle image analyzer(particle shape analyzer) is a microscopic image particle size and particle shape analyzer for non-destructive measurement of coarse particles and millimeter range powder materials. BeVision D2 particle size analyzer’s high speed CCD camera and multi-threaded software quickly identify particles and obtains stable and accurate measurement results. The BeVision D2 particle image analyzer(particle shape analyzer) is a microscopic image particle size and particle shape analyzer for non-destructive measurement of coarse particles and millimeter range powder materials. BeVision D2 particle size analyzer’s high speed CCD camera and multi-threaded software quickly identify particles and obtains stable and accurate measurement results.
Key Features
BeVision D2
- Measurement type: particle shape; particle size
- Particle size range:
Dry: 30µm to 10000µm - Dry dispersion;
- Technology: Automated Imaging
- Measuring range: 30 – 10,000 µm (dry)
- Magnification: 9-300 times
- Repeatability: ≤1% (GBRM D50)
- Accuracy: ≤1% (GBRM D50)
- Optimized software: Identify 10,000 particles per minute. Automatic recognition of agglomerated powder .
- Analysis parameters: Particle size distribution, typical value, maximum particle size, D100, particle shape, aspect ratio, circularity and radius-thickness ratio.
- High-speed CCD camera: 120 images per second, microsecond exposure time, avoid trailing in moving particles .
- Sampler: Dry sampler using electromagnetic vibration feed, gravitydriven dispersion, suitable for coarse and agglomerated particles.
Technical Specifications
| Material | Suspension, emulsion, dry powder |
| Testing parameter | Particle size, particle shape, particle size distribution, etc. |
| CCD | Imaging speed 120 frames/s |
| Measuring speed | 10000pcs/min |
| Typical measurement time | ≤10min |
| Size | |
| Size range | Dry: 30-10000µm |
| Accuracy | ≤1% (GBRM D50) |
| Repeatability | ≤1% (GBRM D50) |
| Magnification | 9-300 times |
| System | |
| Supply voltage | 220/110VAC |
| Dimension | 610mm x 300mm x 450mm (L x W x H) |
| Weight | 26kg |
| Computer specification | |
| Computer interface | At least a USB2.0 port required |
| Operation system | Windows XP, Windows 7,8 or 10 |
| Hardware specification | 500GB HD, CPU: I7 2600 or above; Memory: 4G or above; Mainboard: With PCI-E interface, long and short card slot. Monitor resolution: 1680*1050 or above |
