Binder – Constant Climate Chambers – Series KBF-S Solid.Line – With Large Temperature / Humidity Range

The new Solid.Line KBF-S climate chamber is a custom-made solution for long-term testing and accelerated stability testing for pharmaceutical products in accordance with the ICH Q1A guideline. The corrosion-free and condensation-free interior also ensures exceptionally stable temperature and moisture levels, even when fully loaded.

Inquiry Now

Overview

Features

Specifications

Temperature Range of The KBF-S Series of Constant Climate Chambers

The constant climate chambers in the KBF-S series operate within a temperature range of between 10 °C and 70 °C, and a humidity range of between 20% RH and 80% RH. The proven APT.line™ preheating chamber technology ensures that air is circulated evenly and gently within the usable space, creating the precise and homogeneous climate conditions you need, even when the climate chambers are fully loaded. Humidity is also regulated with precision in the KBF climate chamber thanks to the capacitive humidity sensor and steam humidification. After the door is opened, only a short recovery time is required for the climate in the constant climate chamber to return automatically to the previously set values. The humidity level can be finely adjusted for the needs of the application, suiting your requirements perfectly.

KBF-S Constant Climate Chambers From BINDER For A Wide Range of Applications

KBF-S constant climate chambers from BINDER include an independent, container-based water supply. With their LCD for displaying temperature and humidity, they provide several other features too. Additional information and alarms can also be displayed. The numerous setting options make these climate chambers exceptionally convenient and easy to use on the whole. The stainless steel coating of the inner chamber makes them easy to clean and highly resistant to corrosion, adding another highlight to the long list of benefits afforded by the KBF-S constant climate chambers.

Key Features

Homogeneous climate conditions thanks to APT.line™ preheating chamber
Standard-compliant testing according to ICH Q1A
Precise temperature and humidity control

Technical Specifications

Model	Housing dimensions not incl. fittings and connections W x H x D	Internal dimension W x H x D	Net weight	Interior volume
KBF-S 115	880 x 1050 x 650 mm	600 x 483 x 351 mm	128 kg	102 L
KBF-S 240	925 x 1460 x 800 mm	650 x 785 x 485 mm	189 kg	247 L
KBF-S 720	1250 x 1925 x 890 mm	973 x 1250 x 576 mm	284 kg	700 L
KBF-S 1020	1250 x 1925 x 1145 mm	976 x 1250 x 836 mm	379 kg	1020 L

Available Models

Temperature range: 0 °C to 70 °C
Humidity range: 20% to 80% RH
APT.line™ preheating chamber technology
Humidity regulation with capacitive humidity sensor and steam humidification
LCD to display temperature and humidity along with additional information and alarms
Internal data logger, measured values can be read out in open format via USB
Unit self-test for comprehensive status analysis
Inner chamber made completely of stainless steel
2 stainless steel racks, incl. shelf supports
Access port with silicone plug, 30 mm, left
Robust twin casters with brakes, from 240 L
Class 3.1 independent temperature safety device (DIN 12880) with visual and audible temperature alarm
Computer interface: Ethernet
Independent water supply via tank
